19–24 RAM 68RFE Valve Body
Fits: 2019–2024 Ram trucks equipped with the 68RFE transmission
Features
- Late-model anodized valve body housing
- TRANSGO oversized switch valve plugs
- TRANSGO reverse switch valve
- Dual-seal billet accumulators with redesigned Teflon seals
- Heavy-duty accumulator plate
- Updated upper and lower gaskets added
- Billet channel plate
- New OEM Solenoid Pack ( if optioned )
Quality & Assembly
- All valve body parts are flat-sanded for straightness
- Valve body is vacuum tested
- Aftermarket gaskets installed and torqued twice to ensure no partition leaks
Tuning Compatibility
- Designed to work with transmission tuning up to 250 psi
- Also compatible with stock transmission tuning
Installation Notes
- TCC solenoid not included – you will reuse your original solenoid pack ( DO NOT CONFUSE THE TCC SOLENOID FOR THE VALVE BODY SOLENOID. THESE ARE 2 SEPARATE ITEMS! 2019-2024 ONLY 68RFE )
- No PI curve programming required
- A quick learn procedure is required after installation for proper operation
You must:
- Remove your torque converter solenoid body (see reference picture)
- Remove the check ball (location shown in reference picture)
- Transfer both the solenoid body and check ball to the new valve body assembly
- Torque all related bolts to 60 in-lbs
07.5–18 RAM 68RFE Valve Body
Fits: 2007.5–2018 Ram trucks equipped with the 68RFE transmission
This is our most complete 68RFE valve body package.
Pressure & Tuning
- Valve body will produce whatever pressure the transmission is tuned for
- Most transmission tuning is set to max ~250 psi in forward gears
- Also fully compatible with stock line pressure until the vehicle is tuned for more
Features
- Billet accumulator cover
- Billet channel plate
- Billet accumulators
- TRANSGO reverse switch valve
- TRANSGO oversize switch valve kit
- Gasketed separator plate
- New case-to-valve body seals
- New OEM solenoid pack, designed to fit 2007–2018 68RFE ( if optioned )
Quality & Assembly
- All valve body parts are flat-sanded for straightness
- Valve body is vacuum retested before final assembly
- Aftermarket gaskets are installed and torqued twice to prevent partition leaks
Core Return Policy (07.5–24 Valve Body)
- Core must be in good, reusable condition:
- No broken or cracked parts
- Valve body must be properly bagged to prevent fluid leakage
- Please make sure the valve body is mostly drained of fluid
- If you have any concerns, send us pictures of the core before shipping
Shipping & Documentation
- Core return shipping cost is the customer’s responsibility
- We are not responsible for lost shipments
- Send us a picture of the tracking number once shipped
- Include a copy of your purchase receipt inside the box
WARRANTY
-
Performance valve bodies include a **one-year (12,000-mile) warranty**.
If **engine and transmission tuning** is purchased with the valve body, the warranty is extended to **three years (36,000 miles)**.Electrical components included with some valve bodies—such as sensors, solenoids, and wiring harnesses—are covered by a **90-day warranty**.
- WARRANTY ONLY COVERS VALVE BODY AND RELATED COMPONENTS WE SELL YOU. WARRANTY DOES NOT COVER YOUR ENTIRE TRANSMISSION OR TORQUE CONVERTER NOR THE LABOR TO REMOVE AND INSTALL ANY PARTS!
